Item | Parameters |
OS | Embedded Linux |
System language | English, Spanish, Portuguese, Vietnamese, Russian, Chinese, other(customizable) |
Video compression format | H.265/H.264 compression format |
OSD | Character superposition function, support time and date, vehicle ID and other information image superposition |
GUI | graphic interface | System parameters can be set through external display and remote control operation |
Video and recording system | Video input | 4CH video inputs (aviation plug interface), 1.0Vp-p, 75Ω |
Video output | 1CH mixed video output, 1CH VGA output, 1.0Vp-p, 75Ω |
Preview function | Single-channel or multi-screen splicing preview, support manual/event trigger full-screen display function |
Video resolution | 4CH machine supports 1080P/720P/D1/CIF optional, and the maximum can support 4 channels 1080P 30fps |
Record mode | Default automatic recording, support ACC recording, manual recording, alarm recording, etc. |
Audio | Audio input | 4CH，aviation plug |
Audio output | 1CH，aviation plug |
Format | G.711a compression format, Rate 40KB/s |
Alarm | I/O input | 8CH I/O inputs, with alarm linkage function |
I/O Output | 2CH I/O output |
Serial Port | RS233 | 2 x RS232 |
RS485 | 1 x RS485 |
Network | 4G | Support built-in 4G function |
WiFi | AN5204-G6 support WiFi function |
Wired | Support wired network |
Positioning | Support built-in GPS/BD(GPS/GLONASS) module |
USB | Support 1 x USB interface |
Sensor | Support G-SENSOR acceleration sensor |
Video storage | SD Card | Maximum support 2x512G SD card, loop recording |
File format | H.265/H.264 |
Video playback | Video search | Search for recording video files by recording time, recording mode, etc. |
Playback | Support multi-channel synchronous playback, support fast forward and fast reverse, support 2, 4, 8, 16 times speed optional |
upgrade | Firmware upgrade | Support SD Card and U disk Upgrade, Support Network upgrade |
Power | Power management | Adaptive wide power Voltage input, with protection functions such as overload, overvoltage, undervoltage, short circuit, and reverse connection;Support timing power on/off , delayed power on/off function |
Input voltage | DC:8 ~ 36V |
Consumption | Normal work maximum：5W，standby：0.5W |
working environment | temperature | -20℃ to +70℃ |
humidity | 20% to 80% |
Safety | Password access | Two-level management of user password and administrator password |
Other | Size： | 168(L) x143(W) x 56(H)mm |
